Flowserve Logix Digital Positioner LOGIX 3200IQ-07-D6-E-04-40-0G-00 in Stock

The Flowserve Logix 3200MD Digital HART positioner utilizes state-of-the-art piezo technology to provide superior performance and reliability. The Logix 3200MD can be easily configured using the local buttons, HART handheld, and SoftTools software.1 Terms Concerning Safety The safety terms DANGER, WARNING, CAUTION and NOTE are used in these instructions to highlight particular dangers and/ or to provide additional information on aspects that may not be readily apparent. ! DANGER: Indicates that death, severe personal injury and/ or substantial property damage will occur if proper precau tions are not taken. 0 WARNING: Indicates that death, severe personal injury and/ or substantial property damage can occur if proper precau tions are not taken. 0 WARNING: Substitution of components may impair intrinsic safety. 1 CAUTION: Indicates that minor personal injury and/or prop erty damage can occur if proper precautions are not taken. NOTE: indicates and provides additional technical information, which may not be very obvious even to qualified personnel. Compli ance with other, not particularly emphasized notes, with regard to transport, assembly, operation and maintenance and with regard to technical documentation (e.g., in the operating instruction, product documentation or on the product itself) is essential, in order to avoid faults, which in themselves might directly or indirectly cause severe personal injury or property damage. 2 General Information The following instructions are designed to assist in unpacking, installing and performing maintenance as required on Valtek® Logix® 3200MD digital positioners. Series 3000 is the term used for all the positioners herein; however, specific numbers indicate features specific to model (i.e., Logix 3200 indicates that the positioner has HART® protocol). See Logix 3200MD Model Number table in this manual for a breakdown of specific model numbers. Product users and maintenance personnel should thoroughly review this bulletin prior to installing, operating, or performing any maintenance on the valve. Separate Valtek Flow Control Products Installation, Operation, Maintenance instructions cover the valve (such as IOM 1 or IOM 27) and actuator (such as IOM 2 or IOM 31) portions of the system and other accessories. Refer to the appropriate instructions when this information is needed. To avoid possible injury to personnel or damage to valve parts, WARNING and CAUTION notes must be strictly followed. Modifying this product, substituting non-factory parts or using maintenance procedures other than outlined could drastically affect performance and be hazardous to personnel and equipment, and may void exist ing warranties. WARNING: Standard industry safety practices must be adhered to when working on this or any process control product. Specifically, personal protective and lifting devices must be used as warranted. 3 3.1 Unpacking and Storage Unpacking 1. While unpacking the Logix 3200MD positioner, check the packing list against the materials received. Lists describing the system and accessories are included in each shipping container. 2. When lifting the system from the shipping container, position lifting straps to avoid damage to mounted accessories. Systems with valves up to six inches may be lifted by actuator lifting ring. On larger systems, lift unit using lifting straps or hooks through the yoke legs and outer end of body. 0 WARNING: When lifting a valve/actuator assembly with lifting straps, be aware the center of gravity may be above the lifting point. Therefore, support must be given to prevent the valve/actuator from rotating. Failure to do so can cause serious injury to personnel or damage to nearby equipment. 3. In the event of shipping damage, contact the shipper immediately. 4. Should any problems arise, contact a Flowserve Flow Control Division representative. 3.2 Storage
